•Good looking with safe features
•Easy to operate
•Three-point adjustable belt
•Easy to maintain: change the motors easily (saving time and efforts)
•Two covers on each side of belts to avoid anything getting into the belt.
•Accurately control the speed: Governor with monitor.
•Nickel-plating Screws for good anti-rusting quality.
•Good delivery for specification modular production.
•Applicable to the small object's transportatio
Unit : mm | ||||||||||||
Belt Width (BW) | 200 | 300 | 400 | 500 | 600 | |||||||
Machine Width(MW) | 270 | 370 | 470 | 570 | 670 | |||||||
Working Width (PW) | 170 | 270 | 370 | 470 | 570 | |||||||
Overall Width (TW) | 330 | 430 | 530 | 630 | 730 | |||||||
Machine Length (L) | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 6500 |
7000 | 7500 | 8000 | 8500 | 9000 | 9500 | 10000 | 10500 | 11000 | ||||
Machine Height (H) | 250~1500 | |||||||||||
Frame Material | 30x90mm A60615-T6 High-Strength Aluminum covered by the anodizing surface and film 15UM. | |||||||||||
( 95HB Hardness ) | ||||||||||||
Belt Spec. | Material : PVC , PU (Thickness 1.3 ~ 5mm) | |||||||||||
Color : : Green, Grey, Black and White | ||||||||||||
Pattern : Flat, Cross-Type, Diamond Type | ||||||||||||
Working Temperature：PVC(-10°C~ +80°C) ； PU(-10°C~ +120°C) (Antistatic , wear-resisting , grease-proof) | ||||||||||||
Loading Weight (Kg) | 36 Kgs | 48 Kgs | 60 Kgs | 80 Kgs | 120 Kgs | |||||||
Consumption (W) | 60 W | 90 W | 200 W | 400 W | 750 W | |||||||
Drive Locations | Side Mounted Drive | End Underslung Drive | ||||||||||
Speed (M/MIN) | Standard 6 M／MIN (Fixed) | Standard 3.6 M ／MIN (Adjustable) | ||||||||||
1. 2 . 4 . 6 . 8 . M／MIN | 0~ 2 ; 1~4 ; 3~6 ; 5~17 M／MIN | |||||||||||
Power Supply | AC 110V | AC 220V(Single Phase) | AC 380V | AC 440V | ||||||||
Control Speed Drive | Variable (Adjustable) | Adjustable | Continuous (Fixed) | |||||||||
Electric Wire | Length : 3M | |||||||||||
Roller Dia. (mm) | Knife Edge (front) 35 | Secondary Shaft 85 | Main Shaft (Middle) 85 | |||||||||
Support Type | Aluminum Fixed Support (30x60) with Leg Holder or 4" Brake Casters | |||||||||||
Trimming Strip | Color : Grey and Blue | |||||||||||
Accessories | Aluminum Side Plate Height：60 | |||||||||||
