Roller conveyors are extremely common due to their simplicity, low cost and versatility. Versatility makes roller conveyors suitable for a wide range of applications. The most common are the transport of bulk material and materials handling in factories. Except roller conveyors, we also could provide flexible conveyors, pallet conveyors, belt conveyors, chain conveyors ect. Multiple bearing options, drive options, accessories, assembly options, coatings and more allow us to accommodate almost any application. Rollers can be custom built for extreme temperature ranges, heavy loads, high speeds, dirty, corrosive, and wash-down environments.
Technical parameters
Drive type | Double chains drive/”O”belt drive/”V”belt drive |
The small end diameter of roll | 45/60/90/180 degree |
Turning angle | 900 |
Loading per roller(Width 500mm) | 50kg |
Frame size/material | As your requirements |
Width suitable for carton | As your requirements |
Min height of Conveyor | 500mm |
Formed steel for frame | 120*30*3mm |
Roller sprockets | 08-14T |
Roller code | 2.511.J(a~k)A.ACC |
Roller pitch | 75/100/150mm |
Speed | 25m/min |
Capacity | 250kg/Roller |
Power | 0.2/0.4/0.75 KW |
With O band drive, the nosize is lower.
