• Continuous throughput
• Small footprint
• Reversible as standard
• Suitable for pizza,bread,cake
• Twin lanes avaliable
• Up to 20m max height

Technical parameters

Size for example: φ3500*W500*H10000mm, φ4200*W600*H8000mm

1,Column profile:stainless steel,side plate SUS304
2,Transportation: width=500/600mm
3,Spiral angle:6.9 degree,about 12 circles
4,Speed:1-8m/min,adjustable
5,Conveying width=600/700mm
6,Conveying direction:Up or down
7,Motor:SEW-2.2KW

As standard the spirals are fully reversible for feeding to/from various floors and can also be available in a dual lane version with separate drives which provides continuous flow in both directions.The on board controls features an inverter for altering the speed which can be used for on or off-line buffering and sensors for altering operations of chain stretch.
